How to script a VCF SDDC Manager install on a single Nested ESXi Host!

You have to work hard to get your thinking clean to make it simple. But it’s worth it in the end because once you get there, you can move mountains. - Steve Jobs

Product Versions used for this Blog:

  • VMware Cloud Foundation: 5.2.1
  • PowerCLI: 13.3
  • PowerShell: 7.4.6

Use Case for Creating this Blog

Goals:
  • Leverage my existing Home Lab Hardware to start using and learning about VMware Cloud Foundation (VCF).
  • Enable quick creation or re-creation of a VCF environment.
  • Run VCF on a single Minisforum MS-01 using nested ESXi.
    • For this use case, a vCenter is already set up and running with multiple physical ESXi hosts.
  • Utilize Tiered Memory with the MS-01 to support more VMs and explore how Tiered Memory works.
  • Run the Cloud Builder steps manually to gain hands-on experience, using a JSON file generated by the script for deployment.
  • Install VCF 5.2.1 with the script, then manually upgrade to VCF 5.2.1.1 to learn how SDDC Manager performs upgrades.
  • Manually create Workload Domains to better understand the deployment process and deepen learning.
  • Add the line bringup.mgmt.cluster.minimum.size=1 to the file /etc/vmware/vcf/bringup/application.properties to enable VCF SDDC Manager to run on a single nested ESXi host.
  • Ensure performance is sufficient for learning purposes, without requiring production-level speed.
Initial Considerations:

I explored VMware Holodeck as an option, but the resource requirements were too high for my setup.

Inspiration and Approach:

I came across William Lam’s Blog about running VCF on a single NUC and decided to adapt that idea for my lab. William also provides a PowerShell script that automates the entire VCF installation in a single run. William’s script does require more than one ESXi Host.

Outcome:

After evaluating the available options, I decided to modify some of the example PowerShell scripts and processes to deploy and manage VCF in my Home Lab.

This blog serves as a guide to automate VMware Cloud Foundation (VCF) deployment in a home lab environment. It is also designed as a learning resource for VCF, which is why some steps are performed manually.

By combining automation with hands-on tasks, the goal is to help you understand VCF deployment processes while enabling you to streamline repetitive tasks for future setups.

Whether you’re exploring VCF for the first time or looking to optimize your home lab, this approach provides flexibility to learn, experiment, and refine your deployment strategies.

This blog post shares the scripts and the steps I followed to make it all work.

Home Lab Hardware

Primary Systems:

  • (2) Minisforum MS-01
    • 96 GB memory
    • Intel Core i9-13900H (14 cores: 6 Performance + 8 Efficient)
      • I use all cores and specify which cores to use per VM with Scheduling Affinity rules.
      • VMs like VCF Automation and Operations, I use the performance cores.
      • VMs with light use, I specify the Efficient Cores.
    • Storage Configuration:
      • 1 TB NVMe for Tiered Memory @ 400% (SAMSUNG 990 PRO SSD NVMe)
        • To specify the amount of tiered memory you want to use, you need to set a percentage. This percentage determines how much tiered memory is allocated relative to the physical memory. For example, in my lab, I have 96 GB of physical memory.
        • Using a 400% tiered memory configuration:
           - (96 GB * 400%) + 96 GB physical = 480 GB Total Memory.
      • 4 TB NVMe for Storage (SAMSUNG 990 PRO SSD NVMe)
      • 1 NVMe slot open for future expansion
    • (1) MS-01 runs everything in my lab but the VCF environment
    • (1) MS-01 is dedicated for this VCF environment. All VMs that it takes for a VCF environment

Additional Systems:

  • (2) Apple Mac Minis (Intel-based)
    • Running Fusion and Nested ESXi
    • 64 GB memory each
    • Processors:
      • 1 with Intel i3
      • 1 with Intel i5

Thoughts on the Minisforum MS-01:

  • I’m extremely satisfied with the Minisforum MS-01. If I expand my lab, I plan to add more MS-01 units.
  • The MS-01 includes (2) SFP ports, and I’m considering adding 10 GbE networking to support future lab improvements.
  • The MS-01 CPU fan will run continuously due to the high number of VMs running.
PowerShell Scripts:

Script Overview - Step 1

Purpose: This script automates the creation of the Nested ESXi Host required by VCF Cloud Builder to deploy and configure the VCF environment.

Steps Performed:

  • Create the Nested ESXi Host – Prepares the environment for VCF Cloud Builder to handle the installation and deployment process.
  • This script is designed to install nested ESXi hosts and can be reused for various use cases.
    • By keeping this step as a separate script, it allows flexibility for future deployments beyond this specific lab setup.
    • Update this script with names and IP addresses that match your lab environment.

Click arrow to expand the PowerShell code:

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216

# Script to add Nested ESXi Host
# Author: Dale Hassinger
# Based on Script by: William Lam and other vCommunity Web Sites


# vCenter Server used to deploy VMware Cloud Foundation Lab
$VIServer   = "192.168.6.100"
$VIUsername = "administrator@vcrocs.local"
$VIPassword = "VMware1!"


# Full Path to the Nested ESXi
$NestedESXiApplianceOVA = "/Users/dalehassinger/Downloads/Nested_ESXi8.0u3c_Appliance_Template_v1.ova"


# Nested ESXi VMs for Management Domain
$NestedESXiHostnameToIPsForManagementDomain = @{
    "VCF-DDC-ESX179"   = "192.168.4.179"
} # End Nested Names


# Nested ESXi VM Resources for Management Domain
$NestedESXiMGMTvCPU          = "12"
$NestedESXiMGMTvMEM          = "88" #GB
$NestedESXiMGMTCachingvDisk  = "4" #GB
$NestedESXiMGMTCapacityvDisk = "500" #GB
$NestedESXiMGMTBootDisk      = "32" #GB


# General Deployment Configuration for Nested ESXi
# These Values are for existing existing vCenter Install
#$VMDatacenter = "Datacenter-DB-01"
$VMCluster    = "VCF_LAB"
$VMNetwork    = "VMs"
$VMDatastore  = "ESX-04-2TB"
$VMNetmask    = "255.255.252.0"
$VMGateway    = "192.168.4.1"
$VMDNS        = "192.168.6.1"
$VMNTP        = "time.google.com"
$VMPassword   = "VMware1!"
$VMDomain     = "vcrocs.local"
$VMSyslog     = "192.168.6.94"
#$VMFolder     = "VCF-VMs"


#### DO NOT EDIT BEYOND HERE ####
# 1 = yes
# 0 - no
$confirmDeployment = 1
$deployNestedESXiVMsForMgmt = 1

$StartTimeLogFile = Get-Date -Format "yyyyMMddHHmm"
#$StartTimeLogFile

$verboseLogFile = "vcf-lab-deployment-$StartTimeLogFile.log"
#$verboseLogFile

$StartTime = Get-Date

Function New-LogEvent {
    param(
    [Parameter(Mandatory=$true)][String]$message,
    [Parameter(Mandatory=$false)][String]$color="green"
    )

    $timeStamp = Get-Date -Format "MM-dd-yyyy_hh:mm:ss"

    Write-Host -NoNewline -ForegroundColor White "[$timestamp]"
    Write-Host -ForegroundColor $color " $message"
    $logMessage = "[$timeStamp] $message"
    $logMessage | Out-File -Append -LiteralPath $verboseLogFile
} # End Function



if($confirmDeployment -eq 1) {
    Write-Host -ForegroundColor Magenta "`nNested ESXi Build Details:`n"

    Write-Host -ForegroundColor Yellow "`n---- vCenter Server used to Build Nested ESXi Hosts ----"
    Write-Host -NoNewline -ForegroundColor Green "vCenter Server Address: "
    Write-Host -ForegroundColor White $VIServer
    Write-Host -NoNewline "`n"
    Write-Host -NoNewline -ForegroundColor Green "VM Network: "
    Write-Host -ForegroundColor White $VMNetwork
    Write-Host -NoNewline -ForegroundColor Green "VM Storage: "
    Write-Host -ForegroundColor White $VMDatastore
    Write-Host -NoNewline -ForegroundColor Green "VM Cluster: "
    Write-Host -ForegroundColor White $VMCluster

    if($deployNestedESXiVMsForMgmt -eq 1) {
        Write-Host -ForegroundColor Yellow "`n"
        Write-Host -ForegroundColor Yellow "`---- vESXi Configuration for VCF Management Domain ----"
        Write-Host -NoNewline -ForegroundColor Green "# of Nested ESXi VMs: "
        Write-Host -ForegroundColor White $NestedESXiHostnameToIPsForManagementDomain.count
        Write-Host -NoNewline -ForegroundColor Green "-------IP Address(s): "
        Write-Host -ForegroundColor White $NestedESXiHostnameToIPsForManagementDomain.Values
        Write-Host -NoNewline -ForegroundColor Green "----------------vCPU: "
        Write-Host -ForegroundColor White $NestedESXiMGMTvCPU
        Write-Host -NoNewline -ForegroundColor Green "----------------vMEM: "
        Write-Host -ForegroundColor White "$NestedESXiMGMTvMEM GB"
        Write-Host -NoNewline -ForegroundColor Green "--------Caching VMDK: "
        Write-Host -ForegroundColor White "$NestedESXiMGMTCachingvDisk GB"
        Write-Host -NoNewline -ForegroundColor Green "-------Capacity VMDK: "
        Write-Host -ForegroundColor White "$NestedESXiMGMTCapacityvDisk GB"
    } # End If

    Write-Host -NoNewline "`n"
    Write-Host -NoNewline -ForegroundColor Green "Netmask: "
    Write-Host -ForegroundColor White $VMNetmask
    Write-Host -NoNewline -ForegroundColor Green "Gateway: "
    Write-Host -ForegroundColor White $VMGateway
    Write-Host -NoNewline -ForegroundColor Green "----DNS: "
    Write-Host -ForegroundColor White $VMDNS
    Write-Host -NoNewline -ForegroundColor Green "----NTP: "
    Write-Host -ForegroundColor White $VMNTP
    Write-Host -NoNewline -ForegroundColor Green "-Syslog: "
    Write-Host -ForegroundColor White $VMSyslog
    Write-Host -NoNewline "`n"

} # End If




# Connect to vCenter
if($deployNestedESXiVMsForMgmt -eq 1 -or $deployNestedESXiVMsForWLD -eq 1 -or $deployCloudBuilder -eq 1 -or $moveVMsIntovApp -eq 1) {
    New-LogEvent "Connecting to Management vCenter Server: $VIServer ..."
    $viConnection = Connect-VIServer $VIServer -User $VIUsername -Password $VIPassword -WarningAction SilentlyContinue -Protocol https -Force

    $datastore = Get-Datastore -Server $viConnection -Name $VMDatastore | Select-Object -First 1
    $cluster = Get-Cluster -Server $viConnection -Name $VMCluster
    $vmhost = $cluster | Get-VMHost | Get-Random -Count 1
}





# --- Start Nested ESXi MGT Hosts Build
if($deployNestedESXiVMsForMgmt -eq 1) {
    $NestedESXiHostnameToIPsForManagementDomain.GetEnumerator() | Sort-Object -Property Value | Foreach-Object {
        $VMName = $_.Key
        #Write-Host "VMname:"$VMName
        $VMIPAddress = $_.Value
        #Write-Host "IP:"$VMIPAddress

        $ovfconfig = Get-OvfConfiguration $NestedESXiApplianceOVA
        #$ovfconfig.Common.guestinfo
        $networkMapLabel = ($ovfconfig.ToHashTable().keys | where {$_ -Match "NetworkMapping"}).replace("NetworkMapping.","").replace("-","_").replace(" ","_")
        $ovfconfig.NetworkMapping.$networkMapLabel.value = $VMNetwork
        $ovfconfig.common.guestinfo.hostname.value = "${VMName}.${VMDomain}"
        $ovfconfig.common.guestinfo.ipaddress.value = $VMIPAddress
        $ovfconfig.common.guestinfo.netmask.value = $VMNetmask
        $ovfconfig.common.guestinfo.gateway.value = $VMGateway
        $ovfconfig.common.guestinfo.dns.value = $VMDNS
        $ovfconfig.common.guestinfo.domain.value = $VMDomain
        $ovfconfig.common.guestinfo.ntp.value = $VMNTP
        $ovfconfig.common.guestinfo.syslog.value = $VMSyslog
        $ovfconfig.common.guestinfo.password.value = $VMPassword
        $ovfconfig.common.guestinfo.ssh.value = $true

        New-LogEvent "Deploying Nested ESXi VM $VMName ..."
        $vm = Import-VApp -Source $NestedESXiApplianceOVA -OvfConfiguration $ovfconfig -Name $VMName -Location $VMCluster -VMHost $vmhost -Datastore $datastore -DiskStorageFormat thin -Force

        New-LogEvent "Adding vmnic2/vmnic3 to Nested ESXi VMs ..."
        $vmPortGroup = Get-VirtualNetwork -Name $VMNetwork -Location ($cluster | Get-Datacenter)
        if($vmPortGroup.NetworkType -eq "Distributed") {
            $vmPortGroup = Get-VDPortgroup -Name $VMNetwork
            $vmPortGroup = $vmPortGroup[0]
            New-NetworkAdapter -VM $vm -Type Vmxnet3 -Portgroup $vmPortGroup.Name -StartConnected -confirm:$false | Out-File -Append -LiteralPath $verboseLogFile
            New-NetworkAdapter -VM $vm -Type Vmxnet3 -Portgroup $vmPortGroup.Name -StartConnected -confirm:$false | Out-File -Append -LiteralPath $verboseLogFile
        } else {
            New-NetworkAdapter -VM $vm -Type Vmxnet3 -NetworkName $vmPortGroup.Name -StartConnected -confirm:$false | Out-File -Append -LiteralPath $verboseLogFile
            New-NetworkAdapter -VM $vm -Type Vmxnet3 -NetworkName $vmPortGroup.Name -StartConnected -confirm:$false | Out-File -Append -LiteralPath $verboseLogFile
        } # End If

        $vm | New-AdvancedSetting -name "ethernet2.filter4.name" -value "dvfilter-maclearn" -confirm:$false -ErrorAction SilentlyContinue | Out-File -Append -LiteralPath $verboseLogFile
        $vm | New-AdvancedSetting -Name "ethernet2.filter4.onFailure" -value "failOpen" -confirm:$false -ErrorAction SilentlyContinue | Out-File -Append -LiteralPath $verboseLogFile

        $vm | New-AdvancedSetting -name "ethernet3.filter4.name" -value "dvfilter-maclearn" -confirm:$false -ErrorAction SilentlyContinue | Out-File -Append -LiteralPath $verboseLogFile
        $vm | New-AdvancedSetting -Name "ethernet3.filter4.onFailure" -value "failOpen" -confirm:$false -ErrorAction SilentlyContinue | Out-File -Append -LiteralPath $verboseLogFile

        New-LogEvent "Updating vCPU Count to $NestedESXiMGMTvCPU & vMEM to $NestedESXiMGMTvMEM GB ..."
        Set-VM -Server $viConnection -VM $vm -NumCpu $NestedESXiMGMTvCPU -CoresPerSocket $NestedESXiMGMTvCPU -MemoryGB $NestedESXiMGMTvMEM -Confirm:$false | Out-File -Append -LiteralPath $verboseLogFile

        New-LogEvent "Updating vSAN Cache VMDK size to $NestedESXiMGMTCachingvDisk GB & Capacity VMDK size to $NestedESXiMGMTCapacityvDisk GB ..."
        Get-HardDisk -Server $viConnection -VM $vm -Name "Hard disk 2" | Set-HardDisk -CapacityGB $NestedESXiMGMTCachingvDisk -Confirm:$false | Out-File -Append -LiteralPath $verboseLogFile
        Get-HardDisk -Server $viConnection -VM $vm -Name "Hard disk 3" | Set-HardDisk -CapacityGB $NestedESXiMGMTCapacityvDisk -Confirm:$false | Out-File -Append -LiteralPath $verboseLogFile

        New-LogEvent "Updating vSAN Boot Disk size to $NestedESXiMGMTBootDisk GB ..."
        Get-HardDisk -Server $viConnection -VM $vm -Name "Hard disk 1" | Set-HardDisk -CapacityGB $NestedESXiMGMTBootDisk -Confirm:$false | Out-File -Append -LiteralPath $verboseLogFile

        New-LogEvent "Powering On $vmname ..."
        $vm | Start-Vm -RunAsync | Out-Null

    } # End Foreach

} # End If




if($deployNestedESXiVMsForMgmt -eq 1 -or $deployNestedESXiVMsForWLD -eq 1 -or $deployCloudBuilder -eq 1) {
    New-LogEvent "Disconnecting from $VIServer ..."
    Disconnect-VIServer -Server $viConnection -Confirm:$false
}



$EndTime = Get-Date
$duration = [math]::Round((New-TimeSpan -Start $StartTime -End $EndTime).TotalMinutes,2)

New-LogEvent "VCF Lab Nested ESXi Host Build Complete!"
New-LogEvent "StartTime: $StartTime"
New-LogEvent "EndTime: $EndTime"
New-LogEvent "Duration: $duration minutes to Deploy Nested ESXi Hosts"

Script Overview - Step 2

Purpose: This script automates the setup of VCF Cloud Builder and prepares the configuration required to deploy the VCF Management Domain.

Steps Performed:

  • Creates the Cloud Builder VM – Deploys the virtual machine needed to orchestrate the VCF installation.
  • Generate the JSON Configuration File – Creates the input file required by Cloud Builder to install the VCF Management Domain.
    • The step to create the JSON file is worth reviewing. It is the easiest method I have found to generate the JSON file required for VCF Cloud Builder.
  • Update this script with names and IP addresses that match your lab environment.

Click arrow to expand the PowerShell code:

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
558
559
560
561
562
563
564
565
566
567
568
569
570
571
572
573
574
575
576
577
578
579
580
581
582
583
584
585
586
587
588
589
590
591
592
593
594
595
596
597
598
599
600
601
602
603
604
605
606
607
608
609
610
611
612
613
614
615
616
617
618
619
620
621
622
623
624
625
626
627
628
629
630
631
632
633
634
635
636
637
638
639
640
641
642
643
644
645
646
647
648
649
650
651
652
653
654
655
656
657
658
659
660
661
662
663
664
665
666
667
668
669

# Script to create Cloud Builder VM and json file
# Author: Dale Hassinger
# Based on Script by: William Lam and some other examples I saw on vCommunity sites


# vCenter Server used to deploy VMware Cloud Foundation Lab
$VIServer   = "192.168.6.100"
$VIUsername = "administrator@vcrocs.local"
$VIPassword = "VMware1!"


# Full Path to Cloud Builder OVA
#$CloudBuilderOVA = "/Users/dalehassinger/Downloads/VMware-Cloud-Builder-5.2.0.0-24108943_OVF10.ova"
$CloudBuilderOVA = "/Users/dalehassinger/Downloads/VMware-Cloud-Builder-5.2.1.0-24307856_OVF10.ova"


# VCF Licenses or leave blank for evaluation mode (requires VCF 5.1.1 or later)
$VCSALicense = ""
$ESXILicense = ""
$VSANLicense = ""
$NSXLicense  = ""


# VCF Configurations
$VCFManagementDomainPoolName  = "vcf-m01-rp01"
$VCFManagementDomainJSONFile  = "vcf-mgmt.json"


# Cloud Builder Configurations
$CloudbuilderVMHostname    = "vcf-m01-cb01"
$CloudbuilderFQDN          = "vcf-m01-cb01.vcrocs.local"
$CloudbuilderIP            = "192.168.4.180"
$CloudbuilderAdminUsername = "admin"
$CloudbuilderAdminPassword = "VMw@re123!VMw@re123!"
$CloudbuilderRootPassword  = "VMw@re123!VMw@re123!"


# SDDC Manager Configuration
$SddcManagerHostname      = "vcf-m01-sddcm01"
$SddcManagerIP            = "192.168.4.181"
$SddcManagerVcfPassword   = "VMware1!VMware1!"
$SddcManagerRootPassword  = "VMware1!VMware1!"
$SddcManagerRestPassword  = "VMware1!VMware1!"
$SddcManagerLocalPassword = "VMware1!VMware1!"


$NestedESXiHostnameToIPsForManagementDomain = @{
    "VCF-DDC-ESX179" = "192.168.4.179"
}


# Nested ESXi VM Resources for Management Domain
$NestedESXiMGMTvCPU          = "12"
$NestedESXiMGMTvMEM          = "78" #GB
$NestedESXiMGMTCachingvDisk  = "4" #GB
$NestedESXiMGMTCapacityvDisk = "500" #GB


# Nested ESXi VM Resources for Workload Domain
$NestedESXiWLDvCPU          = "8"
$NestedESXiWLDvMEM          = "36" #GB
$NestedESXiWLDCachingvDisk  = "4" #GB
$NestedESXiWLDCapacityvDisk = "200" #GB


# ESXi Network Configuration
$NestedESXiManagementNetworkCidr = "192.168.4.0/22" # should match $VMNetwork configuration
$NestedESXivMotionNetworkCidr    = "192.168.8.0/24"
$NestedESXivSANNetworkCidr       = "192.168.9.0/24"
$NestedESXiNSXTepNetworkCidr     = "192.168.10.0/24"


# vCenter Configuration
$VCSAName         = "vcf-m01-vc01"
$VCSAIP           = "192.168.4.182"
$VCSARootPassword = "VMware1!"
$VCSASSOPassword  = "VMware1!"
$EnableVCLM       = $true


# NSX Configuration
$NSXManagerSize          = "medium"
$NSXManagerVIPHostname   = "vcf-m01-nsx01"
$NSXManagerVIPIP         = "192.168.4.183"
$NSXManagerNode1Hostname = "vcf-m01-nsx01a"
$NSXManagerNode1IP       = "192.168.4.184"
$NSXRootPassword         = "VMware1!VMware1!"
$NSXAdminPassword        = "VMware1!VMware1!"
$NSXAuditPassword        = "VMware1!VMware1!"


# General Deployment Configuration for Nested ESXi & Cloud Builder VM
# This is information from you current vCenter lab environment
$VMDatacenter = "Datacenter-DB-01"
$VMCluster    = "VCF_LAB"
$VMNetwork    = "VMs"
$VMDatastore  = "ESX-04-2TB"
$VMNetmask    = "255.255.252.0"
$VMGateway    = "192.168.4.1"
$VMDNS        = "192.168.6.1"
$VMNTP        = "time.google.com"
$VMPassword   = "VMware1!"
$VMDomain     = "vcrocs.local"
$VMSyslog     = "192.168.6.94"
$VMFolder     = "VCF-VMs"


#### DO NOT EDIT BEYOND HERE ####

$verboseLogFile    = "vcf-lab-deployment.log"
$random_string     = -join ((65..90) + (97..122) | Get-Random -Count 8 | % {[char]$_})
$VAppName          = "Nested-VCF-Lab-$random_string"
$SeparateNSXSwitch = $false
$VCFVersion        = ""

$preCheck                   = 1
$confirmDeployment          = 1
$deployNestedESXiVMsForMgmt = 1

# WLD Setup
$deployNestedESXiVMsForWLD     = 0
$deployCloudBuilder            = 1
$moveVMsIntovApp               = 1
$generateMgmJson               = 1



$StartTime = Get-Date

Function New-LogEvent {
    param(
    [Parameter(Mandatory=$true)][String]$message,
    [Parameter(Mandatory=$false)][String]$color="green"
    )

    $timeStamp = Get-Date -Format "MM-dd-yyyy_hh:mm:ss"

    Write-Host -NoNewline -ForegroundColor White "[$timestamp]"
    Write-Host -ForegroundColor $color " $message"
    $logMessage = "[$timeStamp] $message"
    $logMessage | Out-File -Append -LiteralPath $verboseLogFile
} # End Function



if($preCheck -eq 1) {
    # Detect VCF version based on Cloud Builder OVA (support is 5.1.0+)
    if($CloudBuilderOVA -match "5.2.0" -or $CloudBuilderOVA -match "5.2.1") {
        $VCFVersion = "5.2.0"
    } elseif($CloudBuilderOVA -match "5.1.1") {
        $VCFVersion = "5.1.1"
    } elseif($CloudBuilderOVA -match "5.1.0") {
        $VCFVersion = "5.1.0"
    } else {
        $VCFVersion = $null
    }

    if($VCFVersion -eq $null) {
        Write-Host -ForegroundColor Red "`nOnly VCF 5.1.0+ is currently supported ...`n"
        exit
    }

    if($VCFVersion -ge "5.2.0") {
        write-host "here"
        if( $CloudbuilderAdminPassword.ToCharArray().count -lt 15 -or $CloudbuilderRootPassword.ToCharArray().count -lt 15) {
            Write-Host -ForegroundColor Red "`nCloud Builder passwords must be 15 characters or longer ...`n"
            exit
        }
    }

    if(!(Test-Path $NestedESXiApplianceOVA)) {
        Write-Host -ForegroundColor Red "`nUnable to find $NestedESXiApplianceOVA ...`n"
        exit
    }

    if(!(Test-Path $CloudBuilderOVA)) {
        Write-Host -ForegroundColor Red "`nUnable to find $CloudBuilderOVA ...`n"
        exit
    }

    if($PSVersionTable.PSEdition -ne "Core") {
        Write-Host -ForegroundColor Red "`tPowerShell Core was not detected, please install that before continuing ... `n"
        exit
    }
}

if($confirmDeployment -eq 1) {
    Write-Host -ForegroundColor Magenta "`nPlease confirm the following configuration will be deployed:`n"

    Write-Host -ForegroundColor Yellow "---- VCF Automated Lab Deployment Configuration ---- "
    Write-Host -NoNewline -ForegroundColor Green "VMware Cloud Foundation Version: "
    Write-Host -ForegroundColor White $VCFVersion
    Write-Host -NoNewline -ForegroundColor Green "Nested ESXi Image Path: "
    Write-Host -ForegroundColor White $NestedESXiApplianceOVA
    Write-Host -NoNewline -ForegroundColor Green "Cloud Builder Image Path: "
    Write-Host -ForegroundColor White $CloudBuilderOVA

    Write-Host -ForegroundColor Yellow "`n---- vCenter Server Deployment Target Configuration ----"
    Write-Host -NoNewline -ForegroundColor Green "vCenter Server Address: "
    Write-Host -ForegroundColor White $VIServer
    Write-Host -NoNewline -ForegroundColor Green "VM Network: "
    Write-Host -ForegroundColor White $VMNetwork

    Write-Host -NoNewline -ForegroundColor Green "VM Storage: "
    Write-Host -ForegroundColor White $VMDatastore
    Write-Host -NoNewline -ForegroundColor Green "VM Cluster: "
    Write-Host -ForegroundColor White $VMCluster
    Write-Host -NoNewline -ForegroundColor Green "VM vApp: "
    Write-Host -ForegroundColor White $VAppName

    Write-Host -ForegroundColor Yellow "`n---- Cloud Builder Configuration ----"
    Write-Host -NoNewline -ForegroundColor Green "Hostname: "
    Write-Host -ForegroundColor White $CloudbuilderVMHostname
    Write-Host -NoNewline -ForegroundColor Green "IP Address: "
    Write-Host -ForegroundColor White $CloudbuilderIP

    if($deployNestedESXiVMsForMgmt -eq 1) {
        Write-Host -ForegroundColor Yellow "`n---- vESXi Configuration for VCF Management Domain ----"
        Write-Host -NoNewline -ForegroundColor Green "# of Nested ESXi VMs: "
        Write-Host -ForegroundColor White $NestedESXiHostnameToIPsForManagementDomain.count
        Write-Host -NoNewline -ForegroundColor Green "IP Address(s): "
        Write-Host -ForegroundColor White $NestedESXiHostnameToIPsForManagementDomain.Values
        Write-Host -NoNewline -ForegroundColor Green "vCPU: "
        Write-Host -ForegroundColor White $NestedESXiMGMTvCPU
        Write-Host -NoNewline -ForegroundColor Green "vMEM: "
        Write-Host -ForegroundColor White "$NestedESXiMGMTvMEM GB"
        Write-Host -NoNewline -ForegroundColor Green "Caching VMDK: "
        Write-Host -ForegroundColor White "$NestedESXiMGMTCachingvDisk GB"
        Write-Host -NoNewline -ForegroundColor Green "Capacity VMDK: "
        Write-Host -ForegroundColor White "$NestedESXiMGMTCapacityvDisk GB"
    } # End If

    if($deployNestedESXiVMsForWLD -eq 1) {
        Write-Host -ForegroundColor Yellow "`n---- vESXi Configuration for VCF Workload Domain ----"
        Write-Host -NoNewline -ForegroundColor Green "# of Nested ESXi VMs: "
        Write-Host -ForegroundColor White $NestedESXiHostnameToIPsForWorkloadDomain.count
        Write-Host -NoNewline -ForegroundColor Green "IP Address(s): "
        Write-Host -ForegroundColor White $NestedESXiHostnameToIPsForWorkloadDomain.Values
        Write-Host -NoNewline -ForegroundColor Green "vCPU: "
        Write-Host -ForegroundColor White $NestedESXiWLDvCPU
        Write-Host -NoNewline -ForegroundColor Green "vMEM: "
        Write-Host -ForegroundColor White "$NestedESXiWLDvMEM GB"
        Write-Host -NoNewline -ForegroundColor Green "Caching VMDK: "
        Write-Host -ForegroundColor White "$NestedESXiWLDCachingvDisk GB"
        Write-Host -NoNewline -ForegroundColor Green "Capacity VMDK: "
        Write-Host -ForegroundColor White "$NestedESXiWLDCapacityvDisk GB"
    } # End If

    Write-Host -NoNewline -ForegroundColor Green "`nNetmask "
    Write-Host -ForegroundColor White $VMNetmask
    Write-Host -NoNewline -ForegroundColor Green "Gateway: "
    Write-Host -ForegroundColor White $VMGateway
    Write-Host -NoNewline -ForegroundColor Green "DNS: "
    Write-Host -ForegroundColor White $VMDNS
    Write-Host -NoNewline -ForegroundColor Green "NTP: "
    Write-Host -ForegroundColor White $VMNTP
    Write-Host -NoNewline -ForegroundColor Green "Syslog: "
    Write-Host -ForegroundColor White $VMSyslog

} # End If


if($deployNestedESXiVMsForMgmt -eq 1 -or $deployNestedESXiVMsForWLD -eq 1 -or $deployCloudBuilder -eq 1 -or $moveVMsIntovApp -eq 1) {
    New-LogEvent "Connecting to Management vCenter Server $VIServer ..."
    $viConnection = Connect-VIServer $VIServer -User $VIUsername -Password $VIPassword -WarningAction SilentlyContinue -Protocol https -Force

    $datastore = Get-Datastore -Server $viConnection -Name $VMDatastore | Select -First 1
    $cluster = Get-Cluster -Server $viConnection -Name $VMCluster
    $vmhost = $cluster | Get-VMHost | Get-Random -Count 1
} # End if


# Start Create Cloud Builder VM
if($deployCloudBuilder -eq 1) {
    $ovfconfig = Get-OvfConfiguration $CloudBuilderOVA

    $networkMapLabel = ($ovfconfig.ToHashTable().keys | where {$_ -Match "NetworkMapping"}).replace("NetworkMapping.","").replace("-","_").replace(" ","_")
    $ovfconfig.NetworkMapping.$networkMapLabel.value = $VMNetwork
    $ovfconfig.common.guestinfo.hostname.value = $CloudbuilderFQDN
    $ovfconfig.common.guestinfo.ip0.value = $CloudbuilderIP
    $ovfconfig.common.guestinfo.netmask0.value = $VMNetmask
    $ovfconfig.common.guestinfo.gateway.value = $VMGateway
    $ovfconfig.common.guestinfo.DNS.value = $VMDNS
    $ovfconfig.common.guestinfo.domain.value = $VMDomain
    $ovfconfig.common.guestinfo.searchpath.value = $VMDomain
    $ovfconfig.common.guestinfo.ntp.value = $VMNTP
    $ovfconfig.common.guestinfo.ADMIN_USERNAME.value = $CloudbuilderAdminUsername
    $ovfconfig.common.guestinfo.ADMIN_PASSWORD.value = $CloudbuilderAdminPassword
    $ovfconfig.common.guestinfo.ROOT_PASSWORD.value = $CloudbuilderRootPassword

    New-LogEvent "Deploying Cloud Builder VM $CloudbuilderVMHostname ..."
    $vm = Import-VApp -Source $CloudBuilderOVA -OvfConfiguration $ovfconfig -Name $CloudbuilderVMHostname -Location $VMCluster -VMHost $vmhost -Datastore $datastore -DiskStorageFormat thin -Force

    New-LogEvent "Powering On $CloudbuilderVMHostname ..."
    $vm | Start-Vm -RunAsync | Out-Null
}


# Move VMs into vApp. Keeps all the VCF VMs together.
if($moveVMsIntovApp -eq 1) {
    # Check whether DRS is enabled as that is required to create vApp
    if((Get-Cluster -Server $viConnection $cluster).DrsEnabled) {
        New-LogEvent "Creating vApp $VAppName ..."
        $rp = Get-ResourcePool -Name Resources -Location $cluster
        $VApp = New-VApp -Name $VAppName -Server $viConnection -Location $cluster

        if(-Not (Get-Folder $VMFolder -ErrorAction Ignore)) {
            New-LogEvent "Creating VM Folder $VMFolder ..."
            $folder = New-Folder -Name $VMFolder -Server $viConnection -Location (Get-Datacenter $VMDatacenter | Get-Folder vm)
        }

        if($deployNestedESXiVMsForMgmt -eq 1) {
            New-LogEvent "Moving Nested ESXi VMs into $VAppName vApp ..."
            $NestedESXiHostnameToIPsForManagementDomain.GetEnumerator() | Sort-Object -Property Value | Foreach-Object {
                $vm = Get-VM -Name $_.Key -Server $viConnection -Location $cluster | where{$_.ResourcePool.Id -eq $rp.Id}
                Move-VM -VM $vm -Server $viConnection -Destination $VApp -Confirm:$false | Out-File -Append -LiteralPath $verboseLogFile
            }
        }

        if($deployNestedESXiVMsForWLD -eq 1) {
            New-LogEvent "Moving Nested ESXi VMs into $VAppName vApp ..."
            $NestedESXiHostnameToIPsForWorkloadDomain.GetEnumerator() | Sort-Object -Property Value | Foreach-Object {
                $vm = Get-VM -Name $_.Key -Server $viConnection -Location $cluster | where{$_.ResourcePool.Id -eq $rp.Id}
                Move-VM -VM $vm -Server $viConnection -Destination $VApp -Confirm:$false | Out-File -Append -LiteralPath $verboseLogFile
            }
        }

        if($deployCloudBuilder -eq 1) {
            $cloudBuilderVM = Get-VM -Name $CloudbuilderVMHostname -Server $viConnection -Location $cluster | where{$_.ResourcePool.Id -eq $rp.Id}
            New-LogEvent "Moving $CloudbuilderVMHostname into $VAppName vApp ..."
            Move-VM -VM $cloudBuilderVM -Server $viConnection -Destination $VApp -Confirm:$false | Out-File -Append -LiteralPath $verboseLogFile
        }

        New-LogEvent "Moving $VAppName to VM Folder $VMFolder ..."
        Move-VApp -Server $viConnection $VAppName -Destination (Get-Folder -Server $viConnection $VMFolder) | Out-File -Append -LiteralPath $verboseLogFile
    } else {
        New-LogEvent "vApp $VAppName will NOT be created as DRS is NOT enabled on vSphere Cluster ${cluster} ..."
    }
}




# Create Cloud Builder json file used to deploy VCF

if($generateMgmJson -eq 1) {
    if($SeparateNSXSwitch) { $useNSX = "false" } else { $useNSX = "true" }

    $esxivMotionNetwork = $NestedESXivMotionNetworkCidr.split("/")[0]
    $esxivMotionNetworkOctects = $esxivMotionNetwork.split(".")
    $esxivMotionGateway = ($esxivMotionNetworkOctects[0..2] -join '.') + ".1"
    $esxivMotionStart = ($esxivMotionNetworkOctects[0..2] -join '.') + ".101"
    $esxivMotionEnd = ($esxivMotionNetworkOctects[0..2] -join '.') + ".118"

    $esxivSANNetwork = $NestedESXivSANNetworkCidr.split("/")[0]
    $esxivSANNetworkOctects = $esxivSANNetwork.split(".")
    $esxivSANGateway = ($esxivSANNetworkOctects[0..2] -join '.') + ".1"
    $esxivSANStart = ($esxivSANNetworkOctects[0..2] -join '.') + ".101"
    $esxivSANEnd = ($esxivSANNetworkOctects[0..2] -join '.') + ".118"

    $esxiNSXTepNetwork = $NestedESXiNSXTepNetworkCidr.split("/")[0]
    $esxiNSXTepNetworkOctects = $esxiNSXTepNetwork.split(".")
    $esxiNSXTepGateway = ($esxiNSXTepNetworkOctects[0..2] -join '.') + ".1"
    $esxiNSXTepStart = ($esxiNSXTepNetworkOctects[0..2] -join '.') + ".101"
    $esxiNSXTepEnd = ($esxiNSXTepNetworkOctects[0..2] -join '.') + ".118"

    $hostSpecs = @()
    $count = 1
    $NestedESXiHostnameToIPsForManagementDomain.GetEnumerator() | Sort-Object -Property Value | Foreach-Object {
        $VMName = $_.Key
        $VMIPAddress = $_.Value

        $hostSpec = [ordered]@{
            "association" = "vcf-m01-dc01"
            "ipAddressPrivate" = [ordered]@{
                "ipAddress" = $VMIPAddress
                "cidr" = $NestedESXiManagementNetworkCidr
                "gateway" = $VMGateway
            }
            "hostname" = $VMName
            "credentials" = [ordered]@{
                "username" = "root"
                "password" = $VMPassword
            }
            "sshThumbprint" = "SHA256:DUMMY_VALUE"
            "sslThumbprint" = "SHA25_DUMMY_VALUE"
            "vSwitch" = "vSwitch0"
            "serverId" = "host-$count"
        }
        $hostSpecs+=$hostSpec
        $count++
    }

    $vcfConfig = [ordered]@{
        "subscriptionLicensing" = $false
        "skipEsxThumbprintValidation" = $true
        "managementPoolName" = $VCFManagementDomainPoolName
        "sddcId" = "vcf-m01"
        "taskName" = "workflowconfig/workflowspec-ems.json"
        "esxLicense" = "$ESXILicense"
        "ceipEnabled" = $true
        "ntpServers" = @($VMNTP)
        "dnsSpec" = [ordered]@{
            "subdomain" = $VMDomain
            "domain" = $VMDomain
            "nameserver" = $VMDNS
        }
        "sddcManagerSpec" = [ordered]@{
            "ipAddress" = $SddcManagerIP
            "netmask" = $VMNetmask
            "hostname" = $SddcManagerHostname
            "localUserPassword" = "$SddcManagerLocalPassword"
            "vcenterId" = "vcenter-1"
            "secondUserCredentials" = [ordered]@{
                "username" = "vcf"
                "password" = $SddcManagerVcfPassword
            }
            "rootUserCredentials" = [ordered]@{
                "username" = "root"
                "password" = $SddcManagerRootPassword
            }
            "restApiCredentials" = [ordered]@{
                "username" = "admin"
                "password" = $SddcManagerRestPassword
            }
        }
        "networkSpecs" = @(
            [ordered]@{
                "networkType" = "MANAGEMENT"
                "subnet" = $NestedESXiManagementNetworkCidr
                "gateway" = $VMGateway
                "vlanId" = "0"
                "mtu" = "1500"
                "portGroupKey" = "vcf-m01-cl01-vds01-pg-mgmt"
                "standbyUplinks" = @()
                "activeUplinks" = @("uplink1","uplink2")
            }
            [ordered]@{
                "networkType" = "VMOTION"
                "subnet" = $NestedESXivMotionNetworkCidr
                "gateway" = $esxivMotionGateway
                "vlanId" = "0"
                "mtu" = "9000"
                "portGroupKey" = "vcf-m01-cl01-vds01-pg-vmotion"
                "association" = "vcf-m01-dc01"
                "includeIpAddressRanges" = @(@{"startIpAddress" = $esxivMotionStart;"endIpAddress" = $esxivMotionEnd})
                "standbyUplinks" = @()
                "activeUplinks" = @("uplink1","uplink2")
            }
            [ordered]@{
                "networkType" = "VSAN"
                "subnet" = $NestedESXivSANNetworkCidr
                "gateway"= $esxivSANGateway
                "vlanId" = "0"
                "mtu" = "9000"
                "portGroupKey" = "vcf-m01-cl01-vds01-pg-vsan"
                "includeIpAddressRanges" = @(@{"startIpAddress" = $esxivSANStart;"endIpAddress" = $esxivSANEnd})
                "standbyUplinks" = @()
                "activeUplinks" = @("uplink1","uplink2")
            }
        )
        "nsxtSpec" = [ordered]@{
            "nsxtManagerSize" = $NSXManagerSize
            "nsxtManagers" = @(@{"hostname" = $NSXManagerNode1Hostname;"ip" = $NSXManagerNode1IP})
            "rootNsxtManagerPassword" = $NSXRootPassword
            "nsxtAdminPassword" = $NSXAdminPassword
            "nsxtAuditPassword" = $NSXAuditPassword
            "rootLoginEnabledForNsxtManager" = $true
            "sshEnabledForNsxtManager" = $true
            "overLayTransportZone" = [ordered]@{
                "zoneName" = "vcf-m01-tz-overlay01"
                "networkName" = "netName-overlay"
            }
            "vlanTransportZone" = [ordered]@{
                "zoneName" = "vcf-m01-tz-vlan01"
                "networkName" = "netName-vlan"
            }
            "vip" = $NSXManagerVIPIP
            "vipFqdn" = $NSXManagerVIPHostname
            "nsxtLicense" = $NSXLicense
            "transportVlanId" = "2005"
            "ipAddressPoolSpec" = [ordered]@{
                "name" = "vcf-m01-c101-tep01"
                "description" = "ESXi Host Overlay TEP IP Pool"
                "subnets" = @(
                    @{
                        "ipAddressPoolRanges" = @(@{"start" = $esxiNSXTepStart;"end" = $esxiNSXTepEnd})
                        "cidr" = $NestedESXiNSXTepNetworkCidr
                        "gateway" = $esxiNSXTepGateway
                    }
                )
            }
        }
        "vsanSpec" = [ordered]@{
            "vsanName" = "vsan-1"
            "vsanDedup" = "false"
            "licenseFile" = $VSANLicense
            "datastoreName" = "vcf-m01-cl01-ds-vsan01"
        }
        "dvSwitchVersion" = "7.0.0"
        "dvsSpecs" = @(
            [ordered]@{
                "dvsName" = "vcf-m01-cl01-vds01"
                "vcenterId" = "vcenter-1"
                "vmnics" = @("vmnic0","vmnic1")
                "mtu" = "9000"
                "networks" = @(
                    "MANAGEMENT",
                    "VMOTION",
                    "VSAN"
                )
                "niocSpecs" = @(
                    @{"trafficType"="VSAN";"value"="HIGH"}
                    @{"trafficType"="VMOTION";"value"="LOW"}
                    @{"trafficType"="VDP";"value"="LOW"}
                    @{"trafficType"="VIRTUALMACHINE";"value"="HIGH"}
                    @{"trafficType"="MANAGEMENT";"value"="NORMAL"}
                    @{"trafficType"="NFS";"value"="LOW"}
                    @{"trafficType"="HBR";"value"="LOW"}
                    @{"trafficType"="FAULTTOLERANCE";"value"="LOW"}
                    @{"trafficType"="ISCSI";"value"="LOW"}
                )
                "isUsedByNsxt" = $useNSX
            }
        )
        "clusterSpec" = [ordered]@{
            "clusterName" = "vcf-m01-cl01"
            "vcenterName" = "vcenter-1"
            "clusterEvcMode" = ""
            "hostFailuresToTolerate" = 0
            "vmFolders" = [ordered] @{
                "MANAGEMENT" = "vcf-m01-fd-mgmt"
                "NETWORKING" = "vcf-m01-fd-nsx"
                "EDGENODES" = "vcf-m01-fd-edge"
            }
            "clusterImageEnabled" = $EnableVCLM
        }
        "resourcePoolSpecs" =@(
            [ordered]@{
                "name" = "vcf-m01-cl01-rp-sddc-mgmt"
                "type" = "management"
                "cpuReservationPercentage" = 0
                "cpuLimit" = -1
                "cpuReservationExpandable" = $true
                "cpuSharesLevel" = "normal"
                "cpuSharesValue" = 0
                "memoryReservationMb" = 0
                "memoryLimit" = -1
                "memoryReservationExpandable" = $true
                "memorySharesLevel" = "normal"
                "memorySharesValue" = 0
            }
            [ordered]@{
                "name" = "vcf-m01-cl01-rp-sddc-edge"
                "type" = "network"
                "cpuReservationPercentage" = 0
                "cpuLimit" = -1
                "cpuReservationExpandable" = $true
                "cpuSharesLevel" = "normal"
                "cpuSharesValue" = 0
                "memoryReservationPercentage" = 0
                "memoryLimit" = -1
                "memoryReservationExpandable" = $true
                "memorySharesLevel" = "normal"
                "memorySharesValue" = 0
            }
            [ordered]@{
                "name" = "vcf-m01-cl01-rp-user-edge"
                "type" = "compute"
                "cpuReservationPercentage" = 0
                "cpuLimit" = -1
                "cpuReservationExpandable" = $true
                "cpuSharesLevel" = "normal"
                "cpuSharesValue" = 0
                "memoryReservationPercentage" = 0
                "memoryLimit" = -1
                "memoryReservationExpandable" = $true
                "memorySharesLevel" = "normal"
                "memorySharesValue" = 0
            }
            [ordered]@{
                "name" = "vcf-m01-cl01-rp-user-vm"
                "type" = "compute"
                "cpuReservationPercentage" = 0
                "cpuLimit" = -1
                "cpuReservationExpandable" = $true
                "cpuSharesLevel" = "normal"
                "cpuSharesValue" = 0
                "memoryReservationPercentage" = 0
                "memoryLimit" = -1
                "memoryReservationExpandable" = $true
                "memorySharesLevel" = "normal"
                "memorySharesValue" = 0
            }
        )
        "pscSpecs" = @(
            [ordered]@{
                "pscId" = "psc-1"
                "vcenterId" = "vcenter-1"
                "adminUserSsoPassword" = $VCSASSOPassword
                "pscSsoSpec" = @{"ssoDomain"="vsphere.local"}
            }
        )
        "vcenterSpec" = [ordered]@{
            "vcenterIp" = $VCSAIP
            "vcenterHostname" = $VCSAName
            "vcenterId" = "vcenter-1"
            "licenseFile" = $VCSALicense
            "vmSize" = "tiny"
            "storageSize" = ""
            "rootVcenterPassword" = $VCSARootPassword
        }
        "hostSpecs" = $hostSpecs
        "excludedComponents" = @("NSX-V", "AVN", "EBGP")
    }

    if($SeparateNSXSwitch) {
        $sepNsxSwitchSpec = [ordered]@{
            "dvsName" = "vcf-m01-nsx-vds01"
            "vcenterId" = "vcenter-1"
            "vmnics" = @("vmnic2","vmnic3")
            "mtu" = 9000
            "networks" = @()
            "isUsedByNsxt" = $true

        }
        $vcfConfig.dvsSpecs+=$sepNsxSwitchSpec
    }

    # License Later feature only applicable for VCF 5.1.1 and later
    if($VCFVersion -ge "5.1.1") {
        if($VCSALicense -eq "" -and $ESXILicense -eq "" -and $VSANLicense -eq "" -and $NSXLicense -eq "") {
            $EvaluationMode = $true
        } else {
            $EvaluationMode = $false
        }
        $vcfConfig.add("deployWithoutLicenseKeys",$EvaluationMode)
    }

    New-LogEvent "Generating Cloud Builder VCF Management Domain configuration deployment file $VCFManagementDomainJSONFile"
    $vcfConfig | ConvertTo-Json -Depth 20 | Out-File -LiteralPath $VCFManagementDomainJSONFile
}

# Make Config Change to Cloud Builder to work with only one Host
$vm = Get-VM -Name $CloudbuilderVMHostname
$o = Invoke-VMScript -VM $vm -ScriptText 'echo "bringup.mgmt.cluster.minimum.size=1" >> /etc/vmware/vcf/bringup/application.properties' -GuestUser "root" -GuestPassword $CloudbuilderRootPassword -ScriptType Bash
$o = Invoke-VMScript -VM $vm -ScriptText 'cat /etc/vmware/vcf/bringup/application.properties' -GuestUser "root" -GuestPassword $CloudbuilderRootPassword -ScriptType Bash
$o = Invoke-VMScript -VM $vm -ScriptText 'systemctl restart vcf-bringup.service' -GuestUser "root" -GuestPassword $CloudbuilderRootPassword -ScriptType Bash

$o = Invoke-VMScript -VM $VM -ScriptText "systemctl status vcf-bringup.service" -GuestUser "root" -GuestPassword $CloudbuilderRootPassword -ScriptType Bash
# Extract the service Status
$outPut = ($o.ScriptOutput -split "`n")[2] -replace 'since.*', '' -replace '^\s+', ''
Write-Host "VCF Bringup Service:"$outPut


# Disconnect from vCenter
if($deployNestedESXiVMsForMgmt -eq 1 -or $deployNestedESXiVMsForWLD -eq 1 -or $deployCloudBuilder -eq 1) {
    New-LogEvent "Disconnecting from $VIServer ..."
    Disconnect-VIServer -Server $viConnection -Confirm:$false
}


$EndTime = Get-Date
$duration = [math]::Round((New-TimeSpan -Start $StartTime -End $EndTime).TotalMinutes,2)

New-LogEvent "VCF Lab Deployment Complete!"
New-LogEvent "StartTime: $StartTime"
New-LogEvent "EndTime: $EndTime"
New-LogEvent "Duration: $duration minutes to Deploy CloudBuilder"

Screen Shots:

Screen Shot of the Physical Host (MS-01), Capacity and Usage, before any installs:

  • The server is equipped with 96 GB of physical memory. Using ESXi Tiered Memory, the total available memory is approximately 478 GB.
/vcf-deploy-home-lab/vcf-deploy-09.png
Click to see Larger Image of Screen Shot

Screen Shot of the Nested ESXi install PowerShell Script output:

  • Total Script Run Time is less than one minute
/vcf-deploy-home-lab/vcf-deploy-10.png
Click to see Larger Image of Screen Shot

Screen Shot of the Physical Host (MS-01), Capacity and Usage, after the Nested ESXi install:

  • Very little CPU/Memory Usage
/vcf-deploy-home-lab/vcf-deploy-11.png
Click to see Larger Image of Screen Shot

Screen Shot of the VCF Cloud Builder VM install PowerShell Script output:

  • Total Script Run Time is ~6.5 minutes
/vcf-deploy-home-lab/vcf-deploy-12.png
Click to see Larger Image of Screen Shot

Screen Shot of the Physical Host (MS-01), Capacity and Usage, after the Nested ESXi and VCF Cloud Builder install:

  • Still very little CPU/Memory Usage
  • Both VMs moved to a vAPP by the Script
/vcf-deploy-home-lab/vcf-deploy-13.png
Click to see Larger Image of Screen Shot

Screen Shot of VCF Cloud Builder Deploy wizard, step 1:

/vcf-deploy-home-lab/vcf-deploy-14.png
Click to see Larger Image of Screen Shot

Screen Shot of VCF Cloud Builder Deploy wizard, step 2:

/vcf-deploy-home-lab/vcf-deploy-15.png
Click to see Larger Image of Screen Shot

Screen Shot of VCF Cloud Builder Deploy wizard, step 3:

/vcf-deploy-home-lab/vcf-deploy-16.png
Click to see Larger Image of Screen Shot

Screen Shot of VCF Cloud Builder Deploy wizard, step 4:

/vcf-deploy-home-lab/vcf-deploy-17.png
Click to see Larger Image of Screen Shot

Screen Shot of VCF Cloud Builder Deploy wizard, step 5:

/vcf-deploy-home-lab/vcf-deploy-18.png
Click to see Larger Image of Screen Shot

Screen Shot of the VCF Cloud Builder - All validation is successful:

/vcf-deploy-home-lab/vcf-deploy-03.png
Click to see Larger Image of Screen Shot

Screen Shot of VCF Cloud Builder Deploy wizard, step 6, start the VCF SDDC Deploy:

/vcf-deploy-home-lab/vcf-deploy-19.png
Click to see Larger Image of Screen Shot

Screen Shot of the VCF Cloud Builder - A successful VCF deployment!

/vcf-deploy-home-lab/vcf-deploy-20.png
Click to see Larger Image of Screen Shot

Screen Shot of the VCF Cloud Builder - Press button to launch SDDC Manager.

/vcf-deploy-home-lab/vcf-deploy-21.png
Click to see Larger Image of Screen Shot

Screen Shot of the VCF SDDC Manager.

/vcf-deploy-home-lab/vcf-deploy-05.png
Click to see Larger Image of Screen Shot

Screen Shot of the VCF SDDC Manager - By installing version 5.2.1, I also have the opportunity to upgrade to 5.2.1.1 and learn the upgrade process:

/vcf-deploy-home-lab/vcf-deploy-06.png
Click to see Larger Image of Screen Shot

Screen Shot of the VCF SDDC Manager - You can see that the performance is good for a Home Lab environment:

/vcf-deploy-home-lab/vcf-deploy-07.png
Click to see Larger Image of Screen Shot

Screen Shot of the Physical Host (MS-01), Capacity and Usage, after the installs are complete:

  • CPU/Memory/Storage all look OK
/vcf-deploy-home-lab/vcf-deploy-22.png
Click to see Larger Image of Screen Shot

Screen Shot of the Physical ESXi Host vSwitch Security settings that is running the nested ESXi Host:

/vcf-deploy-home-lab/vcf-deploy-08.png
Click to see Larger Image of Screen Shot
Lessons Learned:
  • Update the security settings on the vSwitch of the physical ESXi hosts running the nested ESXi hosts to ensure proper configuration (Refer to the screenshot above.)
  • MAKE SURE DNS IS SETUP WITH THE NAMES AND IPs YOU SPECIFY IN THE SCRIPT! If the install fails, it is probably a DNS issue!
  • This script takes approximately 1.25 to 1.5 hours to run and create a VCF SDDC Manager environment.
  • If monitoring the logs, expect periods with no new log entries. Be patient—the process will complete.
    • Example commands to monitor the install logs of Cloud Builder:
      • tail -f -n 45 /var/log/vmware/vcf/bringup/vcf-bringup.log
      • less /var/log/vmware/vcf/bringup/vcf-bringup.log
  • I have run these scripts multiple times, and they have completed successfully.
  • Command to make sure the changes to allow a single ESXi can be used for VCF SDDC Manager on the Cloud Builder VM:
    • The script will complete this step. This is the command to run if you want to verify.
    • cat /etc/vmware/vcf/bringup/application.properties
  • Command to restart the vcf-bringup.service on the Cloud Builder VM:
    • The script will complete this step. This is the command to run if you want to run manually.
    • systemctl restart vcf-bringup.service
  • Check out Brock Peterson blogs for example VCF Operations Dashboards to monitor your VCF environments. Best VCF Operations Blog site available!
  • I also have the example code saved in my GitHub Repository
  • In this blog, I used a single Nested ESXi host to keep things simple, and the performance has been fine for a home lab setup.
    • If you want to expand your environment, you can add additional Nested ESXi Hosts. You can either modify the deployment script or manually add more ESXi hosts to the SDDC Manager after the installation to better understand the process.
  • After the VCF SDDC Manager is installed and running, you can safely delete the Cloud Builder from vCenter to free up space and resources.

Downloading the Nested ESXi Virtual Appliances from VMware Fling Site

For those looking to deploy a Nested ESXi Virtual Appliance, VMware provides pre-configured templates available on their Fling site.

➡️ Click here to access the downloads

Important Note for macOS Users

The Nested ESXi Virtual Appliance downloads are packaged as ZIP files. However, do not double-click to unpack them on macOS, as it may lead to issues with the extracted contents.

Instead, use the command line to properly extract the ZIP file:

1

unzip Nested_ESXi8_0u3c_Appliance_Template_v1_ova-dl.zip

Links to Help with Nested ESXi and VCF on NUC:

Info
In my blogs, I often emphasize that there are multiple methods to achieve the same objective. This article presents just one of the many ways you can tackle this task. I’ve shared what I believe to be an effective approach for this particular use case, but keep in mind that every organization and environment varies. There’s no definitive right or wrong way to accomplish the tasks discussed in this article.
Lab
Always test new setups and processes, like those discussed in this blog, in a lab environment before implementing them in a production environment.
Tips and Tricks
If you found this blog article helpful and it assisted you, consider buying me a coffee to kickstart my day.
Updated on 2024-12-31
 VCF, Automation, Operations, PowerShell
Back | Home
