VCF Operations | Extract Diagnostics Events Script

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145

# Import the ImportExcel module (requires prior installation)
Import-Module ImportExcel

# ----- Configuration and Credentials (Replace with secure methods in production) -----
$opsURL      = "https://vao.vcrocs.local" # Your VCF Operations URL
$opsUsername = "admin"
$opsPassword = "VMware1!" # Use a secure vault or secret manager in production
$authSource  = "local"

# ----- Acquire Aria Operations Token -----
$uri = "$opsURL/suite-api/api/auth/token/acquire?_no_links=true"

# Create authentication body
$bodyHashtable = @{
    username   = $opsUsername
    authSource = $authSource
    password   = $opsPassword
}

# Convert body to JSON
$body = $bodyHashtable | ConvertTo-Json

# Request token
$token = Invoke-RestMethod -Uri $uri -Method Post -Headers @{
    "accept" = "application/json"
    "Content-Type" = "application/json"
} -Body $body -SkipCertificateCheck

$authorization = "OpsToken " + $token.token

# ----- Retrieve Diagnostic Events -----
$uri = "$opsURL/suite-api/internal/events?active=true&diagnosticSubType=HEALTH&page=0&pageSize=1000&type=DIAGNOSTIC&_no_links=true"

$results = Invoke-RestMethod -Uri $uri -Method Get -Headers @{
    "accept" = "application/json"
    "X-Ops-API-use-unsupported" = "true"
    "Authorization" = $authorization
} -SkipCertificateCheck

$OPSDiagData = $results.events

# ----- Prepare Excel Output -----
$excelFilePath = "/Users/hdale/github/PS-TAM-Lab/aria-operations-diag-data.xlsx"
$sheetName     = "Diagnostic-Data"

# Clear existing data in the worksheet
Export-Excel -Path $excelFilePath -WorksheetName $sheetName -ClearSheet

# ----- Process Events and Export Data -----
Try {
    foreach($OPSDiagEvent in $OPSDiagData){
        # Extract resource ID and clean up message content
        $resourceId     = $OPSDiagEvent.resourceId
        $messageContent = $OPSDiagEvent.message -replace "[:_]", " "

        # Remove GUID patterns from messages
        $regex = "[0-9a-f]{8}-[0-9a-f]{4}-[0-9a-f]{4}-[0-9a-f]{4}-[0-9a-f]{12}"
        $messageContent = $messageContent -replace $regex, "" | ForEach-Object { $_.TrimStart() }

        # Process Rule ID and generate Event Link
        $ruleID = $OPSDiagEvent.details | Where-Object { $_.key -eq "ruleId" } | Select-Object -ExpandProperty value
        $eventLink = ""

        if ($ruleID -match "KB_(\d{5,7})$") {
            $KBNumber  = $matches[1]
            $eventLink = "https://knowledge.broadcom.com/external/article?legacyId=$KBNumber"
        } elseif ($ruleID -match "CVE_\d{4}_\d{5}") {
            $CVENumber = $matches[0] -replace "_", "-"
            $eventLink = "https://support.broadcom.com/web/ecx/search?searchString=$CVENumber"
        } elseif ($ruleID -match "VMSA_(\d{4})(\d{2})") {
            $CVENumber = "VMSA-$($matches[1])-00$($matches[2])"
            $eventLink = "https://www.vmware.com/security/advisories/$CVENumber.html"
        } else {
            $eventLink = "NA"
        }

        # Fetch Resource Details
        $uri = $opsURL + '/suite-api/api/resources/' + $resourceId + '?_no_links=true'
        $IDresults = Invoke-RestMethod -Uri $uri -Method Get -Headers @{
            "accept" = "application/json"
            "Authorization" = $authorization
        } -SkipCertificateCheck

        # Prepare data for export
        $newData = @(
            [PSCustomObject]@{
                EventID=$OPSDiagEvent.eventId;
                EventType=$OPSDiagEvent.eventType;
                EventSubType=$OPSDiagEvent.diagnosticSubType;
                Severity=$OPSDiagEvent.severity;
                ResourceName=$IDresults.resourceKey.name;
                AdapterKind=$IDresults.resourceKey.adapterKindKey;
                ResourceKind=$IDresults.resourceKey.resourceKindKey;
                Message=$messageContent;
                Event_Link=$eventLink
            }
        )

        # Append data to Excel sheet
        $newData | Export-Excel -Path $excelFilePath -WorksheetName $sheetName -Append
    }
} Catch {
    Write-Error "An error occurred: $_"
}

# ----- Email Report with Excel Attachment -----
$fromEmail = "dale.hassinger@gmail.com"
$toEmail   = "dale.hassinger@vcrocs.info"
$subject   = "VCF Operations Diagnostic Data"

# Build email body
$body = '<!DOCTYPE html><html><head><meta charset="UTF-8"><title>vCROCS Automation</title><style>body {font-family: Arial;}</style></head><body><p>Diagnostic Data attached.</p><p>Created By: vCROCS Automation</p></body></html>'

$smtpServer  = "smtp.gmail.com"
$smtpPort    = 587
$appPassword = "kl-HackMe-tl"

$emailMessage            = New-Object system.net.mail.mailmessage
$emailMessage.From       = $fromEmail
$emailMessage.To.Add($toEmail)
$emailMessage.Subject    = $subject
$emailMessage.Body       = $body
$emailMessage.IsBodyHtml = $true

if (Test-Path $excelFilePath) {
    $attachment = New-Object System.Net.Mail.Attachment($excelFilePath)
    $emailMessage.Attachments.Add($attachment)
} else {
    Write-Host "Attachment not found: $excelFilePath"
    exit 1
}

$smtpClient             = New-Object system.net.mail.smtpclient($smtpServer, $smtpPort)
$smtpClient.EnableSsl   = $true
$smtpClient.Credentials = New-Object System.Net.NetworkCredential($fromEmail, $appPassword)

try {
    $smtpClient.Send($emailMessage)
    Write-Host "Email sent successfully."
} catch {
    Write-Host "Failed to send email: $_"
}
$smtpClient.Dispose()
$attachment.Dispose()
